Studio Apps

A Studio App is a Vite + React single-page application that lives in your project repository. Datazone installs its dependencies, builds it in an isolated sandbox, and serves the result at a URL inside your deployment — behind the same session that protects the rest of Datazone. Unlike an Intelligent App, which you describe declaratively in YAML, a Studio App is code you write. You get the whole React ecosystem and, with it, everything a dashboard cannot do: multi-step forms, write-back to Knowledge Objects, custom interactions, bespoke layouts.

What you get

A real URL, behind your authentication — the app is served from your Datazone deployment and only to signed-in users of the organisation that owns it. There is no separate hosting, no separate login.
The API, already authenticated — the browser sends the user’s Datazone session with every request. The app ships no API key, and every call runs with that user’s permissions.
One build per branch — each branch of your repository builds and serves its own version of the app, so you can review a change on a feature branch before it reaches main.
A pre-wired scaffold — routing, Tailwind 4, the shadcn component setup, and a small Datazone client are generated for you.
Nothing to operate — no Dockerfile, no deployment pipeline, no CDN configuration. Push, then build.

When to use one

Use	Choose
Charts, KPIs, filters over existing datasets	Intelligent App
Users need to create or edit records	Studio App + Knowledge Objects
A custom workflow, wizard, or internal tool	Studio App
Exposing data to another system	Endpoint

An Intelligent App is considerably less work when it fits. Reach for a Studio App when you need behaviour a dashboard cannot express.

How it works

Create the app. Datazone scaffolds a complete Vite + React app into studio/<alias>/ and registers it in your project’s config.yml, in a single commit.
Write your app. Edit the files in the repository — in the built-in code editor, with Orion, or locally with git. Push your changes.
Build. Datazone runs npm install and vite build in a sandboxed job, then publishes the static bundle.
Open it. The app is served at its URL for signed-in members of your organisation.

Registering an app makes it appear in Datazone; it does not build it. Building is an explicit step, so pushing a broken commit never takes down a working app.

The app in your repository

studio/sales_dashboard/
├── package.json          pinned dependencies
├── index.html
├── vite.config.js
├── components.json       shadcn configuration
├── tsconfig.json
└── src/
    ├── main.tsx          router entry
    ├── App.tsx           your routes
    ├── index.css         Tailwind 4 theme
    ├── lib/datazone.ts   the Datazone client
    ├── lib/utils.ts
    ├── components/app-layout.tsx
    └── components/ui/    shadcn components you add

And in config.yml:

studio_apps:
  - alias: sales_dashboard
    name: Sales Dashboard
    path: studio/sales_dashboard

Talking to Datazone

The scaffold includes src/lib/datazone.ts, a small client for the Datazone API. It sends requests same-origin and relative, so the browser attaches the user’s session cookie automatically.

import { callEndpoint, executeQuery, getMe } from "@/lib/datazone"

const user = await getMe()

const rows = await executeQuery<{ region: string; total: number }>(
  "select region, sum(amount) as total from sales group by region",
)

const { records } = await callEndpoint("daily-revenue", { page_size: 50 })

Export	Purpose
`getMe()`	The signed-in user
`executeQuery(sql)`	SQL over the datasets this user can read
`callEndpoint(slug, params)`	Call a published endpoint
`apiFetch(path, init)`	Any other API path
`branch`, `projectId`	The branch this build came from, and the project
`branchQuery(filters)`	Build a `branch=…&filters=…` query string

Permissions are enforced by the API on every call, so a user who cannot read a dataset cannot read it through your app either. There is no API key in the bundle, and none is needed.

Never put an API key, token, or secret in a Studio App. The bundle is JavaScript delivered to the browser — anything in it is visible to everyone who can open the app.

Storing data

A Studio App is static files. It has no database and no server-side code, so anything users create or edit belongs in a Knowledge Object — a versioned entity declared in your repository with a governed CRUD API. That combination is the usual shape of an internal tool: objects for the records, a Studio App for the interface.

import { apiFetch, branch } from "@/lib/datazone"

// Instances are addressed by their `_key`, and every call takes the app's branch.
await apiFetch(`/knowledge-object/${objectId}/instances/${key}?branch=${branch}`, {
  method: "PATCH",
  body: JSON.stringify({ status: "SHIPPED" }),
})

See the Knowledge Objects API for the full surface.

Branches and builds

Every app is built per branch. A branch has its own bundle, its own URL, and its own build history — the app on feat/new-layout is a different deployment from the one on main. Two consequences worth remembering:

After pushing, build again. Datazone marks the served build stale when the branch has moved on, but it does not rebuild on its own.
Branch-scoped data (Knowledge Objects, for example) defaults to your default branch when a request does not name one. The client exports branch for exactly this reason — pass it, or an app on a feature branch will quietly read main’s data.

Build status is one of NOT_BUILT, QUEUED, BUILDING, READY, ERROR, or TIMEOUT. Logs for every build, successful or not, are on the app’s Builds tab.

Building with Orion

Orion knows how Studio Apps are structured and can write one for you — including designing the Knowledge Objects behind it. Describing what you want (“an app to manage orders, with a status filter and a create form”) is usually faster than starting from the scaffold by hand.

Limits

The app is client-side only. No server-side rendering, no API routes, no server secrets.
Dependencies come from npm at build time, from your package.json. Pin exact versions so a rebuild of the same commit installs the same code.
Builds are sandboxed and time-limited. A build that hangs is marked TIMEOUT.
An app belongs to one organisation. Users from other organisations are refused, not merely unable to find it.

Next steps

Getting Started — create, build, and open your first app
Knowledge Objects — where a Studio App’s data belongs
Endpoints — publish a query for your app to call
Project Repository — how config.yml ties it together
